front loader

Titan MT-01

Manufacturer: Metal-Technik

Estimated load capacity
1300 kg
Tractor power
70-90 km
Lifting height
3100 cm
Working pressure
do 190 bar
Drawing angle
43°
Drawing angle
43°
Discharge angle
58°
Discharge angle
58°
Estimated load capacity
1300 kg
Tractor power
70-90 km
Lifting height
3.1 meters
Working pressure
190 bars
Drawing angle
43O
Discharge angle
58O

Technical specifications of the Tytan MT-01 Front Loader

ModelTytan MT-01 MINI
Machine typesuspended
How to hitch to a tractorSupport structure
Lifting height3220 mm
Loader weight (boom only)496 kg
Estimated load capacity1300 kg
draw depth230 mm
Drawing angle34 °
Discharge angle51 °
Working height adjustmenthydraulic
Leveling errormax 3°
Spoon errorMaximum 10°
Working pressure170 bars
Tractor powerdo 80 km
Working speed (max)5 mph
Maximum Transport Speed9.3 mph
Service1 OS.
Noise levelbelow 70 dB

Standard equipment

  • Euroramka
  • Third section
  • Joystick
  • self-leveling

Optional equipment

  • Piston shock absorber for loader
  • Hydraulic closing of the Euro-pallet
  • Deflection indicator
  • Quick coupler
  • Hydraulics for a loader
  • Proportional valve with electric joystick for loader
  • John Deere POWER BEYOND AL161388
  • John Deere POWER BEYOND AL206034
Available colors
The loader can be ordered in a wide range of colors. The loaders are powder coated.
